Open Type CNC Fiber Laser Cutting Machine for Sheet Metal
Model No.: GF-1530
Introduction:
Fiber laser cutting machine for metal sheet cut, using open design and single table, it is enter type of laser for metal cutting. Easy to loading metal sheet and pick the finished metal pieces from any side, Integrated operator valid 270 degree move, easy to operate and save more space.
- Cutting area : 1500mm(W)×3000mm(L)
- Laser source : IPG / nLIGHT fiber laser generator
- Laser power : 1000W (1500W~3000W Optional)
- CNC controller : Cypcut controller
Open Type Fiber Laser Cutting Machine
GF-1530
- Open type structure for easy loading and unloading.
- Single working table saves floor space.
- Drawer trays facilitate the collection and cleaning of small parts and scraps.
- Integrated design provides dual cutting functions for sheet and tube.
- Gantry dual-drive configuration, high damping bed, good rigidity, high speed and high acceleration speed.
- The world’s leading fiber laser resonator and electronic components to ensure superior stability.
| Model No. | GF-1530 |
| Cutting area | 1500mm(W)×3000mm(L) |
| Laser source | Fiber laser resonator |
| Laser power | 1000W (1500W~3000W Optional) |
| Position accuracy | ±0.03mm |
| Repeat position accuracy | ±0.02mm |
| Maximum position speed | 72m/min |
| Acceleration | 1g |
| Graphic formats supported | DXF, DWG, AI, supported AutoCAD, CorelDraw |
| Electric power supply | AC380V 50/60Hz |
| Total power consumption | 10kW |
※ Appearance and specifications are subject to change due to updating.
GOLDEN LASER – FIBER LASER CUTTING SYSTEMS SERIES
|
Automatic Bundle Loader Tube Laser Cutting Machine |
||
|
Model NO. |
P2060A |
P3080A |
|
Pipe Length |
6m |
8m |
|
Pipe Diameter |
20mm-200mm |
20mm-300mm |
|
Laser Power |
1000W / 1200W / 1500W / 2000W / 2500W / 3000W / 4000W / 6000W |
|
|
Fiber Laser Tube Cutting Machine |
||
|
Model NO. |
P2060 |
P3080 |
|
Pipe Length |
6m |
8m |
|
Pipe Diameter |
20mm-200mm |
20mm-300mm |
|
Laser Power |
1000W / 1200W / 1500W / 2000W / 2500W / 3000W / 4000W / 6000W |
|
|
Heavy Duty Pipe Laser Cutting Machine |
|
|
Model NO. |
P30120 |
|
Pipe Length |
12mm |
|
Pipe Diameter |
30mm-300mm |
|
Laser Power |
1000W / 1200W / 1500W / 2000W / 2500W / 3000W / 4000W / 6000W |
|
Full Closed Fiber Laser Cutting Machine with Pallet Exchange Table |
||
|
Model NO. |
Laser Power |
Cutting Area |
|
GF-1530JH |
1000W / 1200W / 1500W / 2000W / 2500W / 3000W / 4000W / 6000W / 8000W |
1500mm×3000mm |
|
GF-2040JH |
2000mm×4000mm |
|
|
GF-2060JH |
2000mm×6000mm |
|
|
GF-2580JH |
2500mm×8000mm |
|
|
Open Type Fiber Laser Cutting Machine |
||
|
Model NO. |
Laser Power |
Cutting Area |
|
GF-1530 |
1000W / 1200W / 1500W / 2000W / 2500W / 3000W |
1500mm×3000mm |
|
GF-1560 |
1500mm×6000mm |
|
|
GF-2040 |
2000mm×4000mm |
|
|
GF-2060 |
2000mm×6000mm |
|
|
Dual Function Fiber Laser Metal Sheet & Tube Cutting Machine |
||
|
Model NO. |
Laser Power |
Cutting Area |
|
GF-1530T |
1000W / 1200W / 1500W / 2000W / 2500W / 3000W |
1500mm×3000mm |
|
GF-1560T |
1500mm×6000mm |
|
|
GF-2040T |
2000mm×4000mm |
|
|
GF-2060T |
2000mm×6000mm |
|
|
High Precision Linear Motor Fiber Laser Cutting Machine |
||
|
Model NO. |
Laser Power |
Cutting Area |
|
GF-6060 |
1000W / 1200W / 1500W |
600mm×600mm |
Fiber Laser Cutting Machine Applicable Materials
Cutting stainless steel, carbon steel, mild steel, alloy steel, galvanized steel, silicon steel, spring steel, titanium sheet, galvanized sheet, iron sheet, inox sheet, aluminum, copper, brass and other metal sheet, metal plate, metal pipe and tube, etc.
Fiber Laser Cutting Machine Applicable Industries
Machinery parts, electrics, sheet metal fabrication, electrical cabinet, kitchenware, elevator panel, hardware tools, metal enclosure, advertising sign letters, lighting lamps, metal crafts, decoration, jewelry, medical instruments, automotive parts and other metal cutting fields.
Fiber Laser Metal Cutting Samples
<< Read more about fiber laser metal cutting samples
Please contact Golden Laser for more specification and quotation about fiber laser cutting machine. Your response of following questions will help us recommend the most suitable machine.
1. What type of metal do you need to cut? Metal sheet or tube? Carbon steel or stainless steel or aluminum or galvanized steel or brass or copper …?
2. If cutting sheet metal, what is the thickness? What working size do you need? If cutting metal tube or pipe, what is wall thickness, diameter and length of the pipe / tube?
3. What is your finished product? What is your application industry?
4. Your name, company name, email, telephone (WhatsApp) and website?
